 Solar Cell Scribing Machine

Automatic Solar Cell Fiber Laser Scribing Machine for PV Module Production Lines

The Automatic Solar Cell Fiber Laser Scribing Machine is a specialized photovoltaic manufacturing equipment designed for solar cell cutting, scribing, and segmentation in PV module production lines. Equipped with a high-precision fiber laser source and an automated positioning system, it enables accurate and consistent processing of silicon solar cells into required sizes and shapes. It is suitable for photovoltaic module manufacturers requiring reliable cell cutting solutions for half-cell and customized cell processing applications.


Key Features

1. High-Precision Fiber Laser Cutting Technology

Utilizes a high-precision fiber laser source to perform accurate scribing and cutting on silicon-based solar cells. It supports full-cell segmentation, half-cell processing, and customized cell cutting for different PV module designs.

2. Non-Contact Processing with Minimal Cell Damage

Adopts non-contact laser processing technology to reduce mechanical stress during solar cell cutting. Controlled laser energy and a narrow heat-affected zone help minimize edge chipping, microcrack risks, and material loss, contributing to improved cell processing quality.

3. Consistent Cutting Quality for Solar Cell Segmentation

Produces narrow and uniform cutting lines with controlled edge quality. Consistent processing helps prepare solar cell segments for subsequent tabber stringer operations and supports the manufacturing requirements of half-cut and multi-segment PV modules.

4. Automated Solar Cell Positioning and Processing

Integrates automated positioning, precision laser processing, and coordinated control to improve processing consistency and reduce manual handling. The system is designed to support efficient solar cell cutting operations in automated photovoltaic manufacturing environments.

5. Designed for PV Module Manufacturing Production Lines

Designed for the solar cell cutting and segmentation stage of PV module production. It supports photovoltaic manufacturers in processing solar cells for subsequent stringing, soldering, and module assembly. Suitable for new PV module production line projects, existing factory upgrades, and customized solar cell processing applications.

Technical Parameters

Machine Model
YHC-30
Laser Type 1064nm Fiber Laser
Beam Quality ㎡
1.3
Worktable  Travel
 800*300mm
Max.Scribing Speed
600mm/s
Scribing Precision
≤0.02mm
Auto Positioning Accuracy
≤±0.05mm
Cooling System
Air Cooling
Processing Range
230*230mm
Compressed Air Requirement
0.5~0.8Mpa
Power Supply
220V/50HZ
Equipment Dimensions2900*930*1740mm

Product Applications

1. Solar Cell Cutting for PV Module Production Lines

The Automatic Solar Cell Fiber Laser Scribing Machine is designed for solar cell cutting and segmentation in photovoltaic (PV) module manufacturing. It precisely processes full-size crystalline silicon solar cells into half-cells or customized cell segments according to different module design requirements. As an important processing device in solar module production lines, it provides a reliable laser cutting solution for manufacturers producing high-efficiency photovoltaic modules.

2. Half-Cut, Third-Cut and Multi-Segmentation Cell Processing

Suitable for half-cut, third-cut, and multi-segment solar cell processing for various photovoltaic module designs. By precisely dividing full-size solar cells into smaller segments, the machine helps reduce the operating current of individual cell sections and associated resistive losses in module circuits. These cell configurations support advanced PV module designs with improved electrical performance and reduced hot spot risks.

3. Solar Cell Cutting Before Stringing and Module Assembly

Integrated into the cell processing stage before tabber stringer operations, the machine cuts full-size solar cells into the required dimensions for subsequent cell interconnection and module assembly. The processed cell segments can be transferred to downstream stringing, soldering, layup, and lamination processes. It is particularly suitable for PV module manufacturers producing half-cut, third-cut, and customized solar cell modules.

4. Cutting for Advanced N-Type Solar Cell Technologies (TOPCon, HJT and IBC)

Designed for laser cutting and segmentation of various high-efficiency crystalline silicon solar cell technologies, including TOPCon, HJT (Heterojunction), and IBC (Interdigitated Back Contact) cells. The high-precision fiber laser processing system supports different cell structures and processing requirements. Its non-contact processing method helps reduce mechanical stress, edge chipping, and thermal impact during cutting, making it suitable for advanced N-type and thinner solar cell processing.

5. New PV Module Production Lines and Existing Factory Upgrades

Suitable for new photovoltaic module manufacturing projects, existing production line upgrades, and automated solar cell processing facilities. The Automatic Solar Cell Fiber Laser Scribing Machine provides a cell cutting solution for manufacturers expanding production capacity, introducing half-cut or multi-segment module technologies, or upgrading existing PV module manufacturing processes.
