Automatic Solar Cell Fiber Laser Scribing Machine

The Automatic Solar Cell Fiber Laser Scribing Machine is designed for high-precision cutting and segmentation of crystalline silicon solar cells in photovoltaic module manufacturing. Equipped with an advanced fiber laser source and an automated positioning system, it delivers fast, accurate, and consistent laser processing with minimal thermal impact on the cells.

The machine enables solar cells to be divided into half-cut, third-cut, and other customized sizes to meet different PV module production requirements. Its non-contact laser processing technology helps reduce mechanical stress, edge chipping, and cell breakage, ensuring reliable processing quality and improved production efficiency.


Product Features

1. High-Precision Fiber Laser Technology

Equipped with a high-performance fiber laser source, the machine performs precise laser scribing and cutting on crystalline silicon solar cells. It enables consistent cell segmentation into half-cut, third-cut, and other customized sizes to meet different photovoltaic module design requirements.

2. Non-Contact Processing with Minimal Thermal Impact

Adopting non-contact laser processing technology, the machine minimizes mechanical stress during cell cutting. Its narrow heat-affected zone (HAZ) and controlled edge chipping help reduce microcracks, cell breakage, and processing damage.

3. Consistent Cutting Quality and Cell Performance

Designed to deliver narrow and uniform cutting kerfs with controlled edge quality, the machine helps maintain the mechanical integrity and electrical performance of processed solar cells, providing reliable quality for subsequent stringing and module assembly processes.

4. Improved Processing Efficiency and Automation

Integrating laser processing, automatic positioning, and motion control, the machine improves cell processing efficiency and operational consistency. It can be configured for different production requirements and integrated into both fully automatic and semi-automatic photovoltaic module manufacturing lines.

5. Flexible Application for Different Production Capacities

Suitable for photovoltaic module manufacturers operating 50MW–300MW production lines, particularly semi-automatic module assembly lines. It also supports integration into fully automatic production lines, providing a flexible solution for manufacturers producing half-cut, third-cut, and other customized solar cell formats.

Technical Specifications

Model
YHC-30
Laser Type 1064nm Fiber Laser
Beam Quality ㎡
1.3
Worktable  Travel X*Y
800*300mm
Maximum Scribing Speed
600mm/s
Scribing Accuracy
≤0.02MM
Auto Positioning Accuracy
≤±0.05mm
Cooling sytem
Air Cooling
Processing Range 230*230
Compressed Air Pressure
0.5~0.8mpa
Power Supply
22v/50hz
Equipment Dimension L*W*H
2900*930*1740mm

Product Applications

1. Solar Cell Cutting and Segmentation

Designed for precision cutting and segmentation of crystalline silicon solar cells, the machine divides full-size solar cells into smaller formats, including half-cut, third-cut, and other customized sizes according to different PV module design requirements.

2. Half-Cut and Multi-Cut Solar Cell Production

Suitable for half-cut and multi-cut solar cell processing, supporting various cell formats used in modern photovoltaic modules. By dividing full-size cells into smaller sections, the process helps reduce operating current and resistive losses in module interconnections, contributing to improved module performance.

3. Processing of Advanced Solar Cell Technologies

Applicable to different crystalline silicon solar cell technologies, including P-type and N-type cells such as PERC, TOPCon, HJT, and IBC, subject to cell structure and process compatibility. Its non-contact laser processing technology helps minimize mechanical stress and thermal impact during cell cutting.

4. Integration into PV Module Production Lines

Designed for integration into both semi-automatic and fully automatic photovoltaic module production lines. Particularly suitable for 50MW–300MW semi-automatic module manufacturing projects, the machine also supports larger-scale automated production facilities, providing flexible solar cell cutting solutions for different production capacities and manufacturing requirements.
