Solar Cell Laser Scribing Machine

The Solar Cell Laser Scribing Machine is a precision laser processing system designed for photovoltaic cell scribing and half-cell processing. Equipped with a precision positioning platform, it enables controlled, non-contact laser processing for compatible solar cell materials.

The machine supports solar cell half-cutting applications, helping manufacturers divide full-size cells into two half-cells, subject to the machine's processing method and configuration. Its non-contact processing approach helps minimize mechanical stress and may reduce the risk of microcracks, edge chipping, and cell breakage when properly configured.

Laser parameters and processing paths can be adjusted according to the cell material, thickness, and processing requirements. The machine is suitable for photovoltaic process development, sample preparation, laboratory testing, and small-batch production requiring flexible operation and precise positioning.



Key Features of the Solar Cell Laser Scribing Machine
-----------------------------------------------------------------------

1. High-Precision Non-Contact Laser Processing

The Solar Cell Laser Scribing Machine uses a high-energy-density fiber laser beam for non-contact processing of compatible photovoltaic cells. By minimizing direct mechanical contact with the cell material, the process helps reduce mechanical stress and the risk of microcracks, edge chipping, and cell breakage. With suitable laser parameters, it supports clean, precise processing while helping protect the electrical performance of solar cells and maintain module yield and long-term reliability.

2. Flexible Manual Operation and Precise Control

Equipped with a high-precision manual X-Y positioning platform, the machine allows operators to flexibly control the laser processing position and movement path on the solar cell. It is suitable for R&D, process testing, sample preparation, and small-batch processing of special-sized solar cells that require flexibility and precision. Its straightforward operating method helps reduce the learning curve for users.

3. Photovoltaic-Specific Processing with Adjustable Parameters

Designed for photovoltaic cell processing, the machine supports adjustable laser parameters, including power, frequency, pulse width, and processing speed, according to the equipment configuration. These parameters can be optimized for compatible solar cell materials, thicknesses, and scribing or cutting requirements. The laser process does not require mechanical cutting tools, eliminating tool wear associated with mechanical cutting and helping reduce processing debris and subsequent cleaning requirements.

4. Stable, Reliable, and Cost-Effective Design

The machine features a long-life fiber laser source with high photoelectric conversion efficiency, supporting stable and reliable operation. Its relatively simple and compact structure offers a cost-effective alternative to fully automated equipment for applications that do not require a complete automated production system. It is suitable for laboratories, pilot production lines, and small-scale manufacturing requiring precise solar cell laser scribing, cutting, or segmentation.

Technical Specifications

Parameter
Specification
Model
YHC-30F
Laser
1064 nm Fiber Laser
Beam Quality m²
1.3
Worktable  Travel
800*300mm
Max.Scribing Speed
600mm/s
Scribing Accuracy
≤0.02MM
Auto Positioing Accuracy
≤±0.05mm
Cooling System
Air Cooling
Processing Range
230*230mm
Compressed Air Pressure
0.5-0.8Mpa
Power Supply
220V/50hz
Dimension (L*W*H)
2900*930*1740mm

Product Applications
------------------------------------------------------------------------------------

1. PV Cell R&D and Process Development

Suitable for laboratories, research institutes, and R&D departments of solar cell manufacturers. The machine supports laser scribing tests and parameter optimization for new cell technologies, helping evaluate edge quality, microcracks, and potential impacts on cell performance.

2. Small-Batch Production and Custom Cell Processing

Ideal for pilot production lines, sample preparation, and small-scale PV module manufacturing. It supports compatible non-standard cell sizes, customized designs, and experimental samples, offering flexible processing for small-batch, multi-variety production.

3. Quality Inspection and Failure Analysis

Used in quality inspection laboratories to prepare solar cell samples for further analysis. It helps engineers examine cut-edge quality, investigate potential defects, evaluate process consistency, and identify opportunities to improve production yield.

4. PV Education and Technical Training

Suitable for vocational schools, training centers, and research institutions teaching photovoltaic processing technologies. The machine provides a practical platform for learning laser scribing principles, parameter adjustment, and precision processing techniques.
